• Global CMOS imaging, flexible LED red light, automatic exposure;
• Adjustable scanning angle for easier barcode scanning;
• Plug and play;
• Supports multiple languages and secondary development;
• Easily reads various 1D and 2D barcodes, including laminated, reflective, blurred, wrinkled, color, and screen barcodes;
• Multi-system support (Windows, Android, Linux, macOS).
| Category | Parameter | Value | Note |
|---|---|---|---|
| GT-8801D Technical Parameter | |||
| Basic Information | Model | GT-8801D Technical Parameter | |
| Basic Information | Item | Wired 2D Image Desktop barcode scanner | |
| Physical Parameter | Material | ABS+TPU | |
| Physical Parameter | Power Supply | DC 5V ±5% | |
| Physical Parameter | Operating Current | 0.12A（Standby）；0.18A（Operating）；0.26A（Max）【Average】 | |
| Physical Parameter | Power consumption | 0.60W（Standby）；0.90W（Operating）；1.30W（Max）【Average】 | |
| Physical Parameter | Weight | 280g±3g（Without cable） | |
| Physical Parameter | Size | L * W * H：106.2 * 105.0 * 155.3（unit：mm） | |
| Physical Parameter | Color | Black，white | |
| Performance Parameter | Interface | USB, USB COM,（RS232 can be customized） | |
| Performance Parameter | System supported | Linux，Android，Windows XP、7、8、10，MAC | |
| Performance Parameter | Language supported | English; Belgium; Finland; France; Germany; Italy; Sweden; Britain; Denmark; Norway; Spain; Portugal; Turkey Q; Turkey F; Japan; Russia; Czech Republic; Thailand; Ukraine; Brazil; Greece; Hungary; Netherlands; Poland; Romania; Slovakia; [Support virtual keyboard] | |
| Performance Parameter | Sensor | Global COMS sensor 640 * 480 | |
| Performance Parameter | Light Source | Fill light: Red LED; Indicator light: Green LED | |
| Performance Parameter | Processor | 32-bit ARM MCU + DSP | |
| Performance Parameter | Motion Tolerance | Code39：0.95m/sec; QR：1.02m/sec | |
| Performance Parameter | Resolution | Code39 ≥4mil | |
| Performance Parameter | Error Rate | 1/5000000 | |
| Performance Parameter | Reading Mode | Image | |
| Performance Parameter | Triggle Mode | Auto-sensing | |
| Performance Parameter | Prompt Mode | Buzzer+Indicator Light(LED) | |
| Performance Parameter | Scanning Angle | Rotation 360°, elevation ± 65°, deflection ± 65° | |
| Performance Parameter | Scan width | 5mm-250mm | |
| Performance Parameter | Scanning distance | 0mm - 400mm | |
| Performance Parameter | Print Contrast | ≥20% | |
| Performance Parameter | Decoding Capability (1D) | Interleaved 2 of 5, ITF-6, ITF-14, ISB-128, Code 11, UCC/EAN-128, GS1 Databar, Industrial 2 of 5, Matrix 2 of 5, Code 32, Code 128, EAN-13, EAN-8, Code 39, UPC-A, Codabar, Standard 2 of 5, Plessey, MSI-Plessey, UPC-E, Code 93, GS1 composite code | |
| Performance Parameter | Decoding Capability (2D) | PDF417, Data Matrix, QR Code, Micro PDF417, HanXin, AZTEC, Maxicode, Micro QR | |
| Performance Parameter | Scanning Depth | QR Code 10.83mil：2cm - 9cm; QR Code 20.83mil：2cm - 21cm; Code 39 5.83mil：1cm - 12cm; Code 39 10.83mil：1cm - 21cm; EAN13 9.17：1cm - 15cm; EAN13 10.83：2cm - 21cm; WeChat：0cm - 43cm; Alipay：0cm - 43cm | |
| Environment Parameter | IP Grade | IP52 | |
| Environment Parameter | Operating Temp. | 0 to 50℃ / 32 to 122℉ | |
| Environment Parameter | Storage Temp. | 0 to 50℃ / 32 to 122℉ | |
| Environment Parameter | Operating Humidity | 20% to 85%（No Condensation） | |
| Environment Parameter | Storage Humidity | 20% to 85%（No Condensation） | |
| Environment Parameter | ESD Protection | 15KV air discharge | |
| Environment Parameter | Shock Resistance | 1.2m free fall on concrete surface | |
| Environment Parameter | Ambient light | 0→100000Lux | |
