Barcode scanner X-SP2C

Function

- Flexible LED red light, adjustable body for easier barcode scanning

· Quickly reads various paper 1D and 2D barcodes, and mobile payment codes

· Easily reads blurry codes, red-background printed codes, laminated codes, and reflective codes

· Supports multiple languages and a virtual keyboard

· Supports 1D/2D scanning mode switching

· Motion tolerance up to 3.24 m/s

· Supports multiple systems: Windows, Android, Linux, and MAC OS

· Scan products and make payments—all in one device, small in size but powerful in function.

Parameters

类别	详情
Material	ABS+PC
Power Supply	DC 5V ±5%
Power Consumption	1.60W（Standby）；0.80W（Operating）；2.24W（Max）[Average]
Weight	294.0g±5g（Without cable）
Size	LWH：146.9985.2789.97（unit: mm）
Color	Black
Interface	USB
System Supported	Linux, Android, Windows XP、7、8、10, MAC
Language Supported	American English; French; German; Hungarian; Italian（Italy 142）; Japanese; Spanish; Finnish; Russian; Polish; Dutch; Arabic; Czech; Portuguese（Portugal）; Portuguese（Brazil）; Greek; Slovenian; Turkish；支持虚拟键盘
Source	Planar CMOS sensor 1600*900
Light Source	Red LED Light
Resolution	Code39:4mil
Bit Error Rate	1/5000000
Motion tolerance	3.24m/sec
Reading Mode	Image
Trigger Mode	Auto-Sensing
Processor	32-bit ARM MCU + DSP
Prompt Mode	buzzer+Indicator Light(LED)
Print Contrast	≥25%
Decoding Capability	1D：interleaved 2 of 5；Standard 2 of 5；Matrix 2 of 5；RSS-14；Code93；Code39-FULLASCII；Code39-Regular；Code128；Codebar；EAN/UCC-128Auto；Codell；JAN/EAN-8；EAN-13；UPC-A 2D：MICRO QR；Data Matrix；QR；Aztec；PDF417
Scanning Angel	Rotation 360°，elevation ±45°，deflection ±45°
Scanning Depth	5mil code39：1cm - 12cm；13mil UPC-A：2cm - 30cm 20mil code39：1cm - 30cm；6.7mil PDF417：1cm - 6cm 10mil Data Matrix：1cm - 12cm；13mil UPC-A：2cm - 20cm Code cutting and scanning mode Payment：10.0cm - 42cm；Payment：20.0cm - 42cm
Key switch	mode 1: 1D；2D scanning；mode 2: only 1D scanning
IP Grade	IP52
Operating Temp.	0 to 50℃ / 32 to 122℉
Storage Temp.	0 to 50℃ / 32 to 122℉
Operating Humidity	20% to 85%（No Condensation）
Storage Humidity	20% to 85%（No Condensation）
ESD Protection	15KV air discharge
Shock Resistance	1.5m free fall on concrete surface

Related Downloads

The following is the information related to this product：

Manual

版本：1.0.0, 2025-12-09
