High-volume product
- Supports 1D barcodes and 8 types of 2D barcodes, suitable for medical, supermarket, and catering industries
- Supports USB KBW and USB COM
- Supports adding and hiding prefixes and suffixes
- Supports online upgrades under Windows
| Category | Parameter | Value |
|---|---|---|
| Product Information | ||
| Product Information | Model No. | XP-760H |
| Product Information | Product Name | 2D Wired Barcode Scanner |
| Physical Parameters | ||
| Physical Parameters | Material | ABS+PC+TPE |
| Physical Parameters | Power Supply | DC 5V ±5% |
| Physical Parameters | Power Consumption | 0.85W（Working）；0.55W（Standby）；1.05W（Maximum） |
| Physical Parameters | Current | 168mA（Working）；109mA（Standby）；200mA（Maximum） |
| Physical Parameters | Weight | 108g±5g（including cable） |
| Physical Parameters | Size | L*W*H：170 * 70 * 88（unit:mm） |
| Physical Parameters | Color | Black or Grey White |
| Physical Parameters | Button Lifetime | ＞200000 |
| Performance Parameters | ||
| Performance Parameters | USB | USB；（RS232 to be optional） |
| Performance Parameters | OS | Linux，Android，Windows XP、7、8、10，MAC |
| Performance Parameters | Keyboard Language | American；French；German；Hungary；Italian；Spanish； 【Virtual Keyboard is supported】 |
| Performance Parameters | Light Source | Red LED(Aiming)+White LED(lighting) |
| Performance Parameters | Resolution | ≥5mil |
| Performance Parameters | Error Rate | 1/500M |
| Performance Parameters | Motion tolerance | code 128:20cm/sec QR:25cm/sec |
| Performance Parameters | Sensor | Planar CMOS sensor |
| Performance Parameters | Reading Mode | Image |
| Performance Parameters | Trigger Mode | Manual Mode,Continuous Scanning Mode |
| Performance Parameters | Reading Range | 10mm-600mm |
| Performance Parameters | Prompt Mode | Buzzer, Indicator Light（LED） |
| Performance Parameters | Print Contrast | 30% |
| Performance Parameters | Reading Angle | Roll360°，Pitch45°，Yew45° |
| Performance Parameters | Decoding Capacility | ● Code25-Interleaved ● Code25-Standard ● Code25-Matri ● RSS-14 ● Code39-Regular ● Code39-FullASCII ● Code93-Regular ● Code93-FullASCII ● Code128 ● Code11 ● UPCE0/E1 ● EAN/GSL/UCC-128Auto ● Codabar ● MSI ● EAN/JAN-13 ● UPC-A ● JAN/EAN-8 |
| Performance Parameters | Scanning Depth | QR 9.17 mil（7 byte）：6cm - 10cm Data Matrix 9.17mil（7 byte)：7cm - 10cm code93 5.83mil（14 byte）：7cm - 10cm |
| Environmental Parameters | ||
| Environmental Parameters | IP | IP42 |
| Environmental Parameters | Operating Temp. | 0 to 50℃ / 32 to 122℉ |
| Environmental Parameters | Storage Temp. | 0 to 50℃ / 32 to 122℉ |
| Environmental Parameters | Operating Humidity | 20% to 85%（No Condensation） |
| Environmental Parameters | Storage Humidity | 20% to 85%（No Condensation） |
| Environmental Parameters | ESD Protection | 15KV air discharge |
| Environmental Parameters | Shock Resistance | 1.2m free fall on concrete |
